The GRIDDATA function interpolates scattered data values on a plane or a sphere to a regular grid, an irregular grid, a specified set of interpolates, or scattered data points. The returned value is a twodimensional floating point array. Computations are performed in doubleprecision floating point. The following interpolation methods are supported:
Inverse Distance (default)

Natural Neighbor

Kriging
Nearest Neighbor

Linear
Polynomial Regression

Minimum Curvature

Quintic
Modified Shepard’s

Radial Basis Function

Note: GRIDDATA accepts complex input but only utilizes the real part of any complex number.
Syntax
Interleaved
Result = GRIDDATA( X, F )
Planar
Result = GRIDDATA( X, Y, F )
Sphere From Cartesian Coordinates
Result = GRIDDATA( X, Y, Z, F, /SPHERE )
Sphere From Spherical Coordinates
Result = GRIDDATA( Lon, Lat, F, /SPHERE )
Inverse Distance Keywords: [, METHOD='InverseDistance'  /INVERSE_DISTANCE ] [, ANISOTROPY=vector ] [, /DEGREES ] [, DELTA=vector ] [, DIMENSION=vector ] [, TRIANGLES=array [, EMPTY_SECTORS=value ] [, MAX_PER_SECTOR=value ] [, MIN_POINTS=value ] [, SEARCH_ELLIPSE=vector ] ] [, FAULT_POLYGONS=vector ] [, FAULT_XY=array ] [, /GRID, XOUT=vector, YOUT=vector ] [, MISSING=value ] [, POWER=value ] [, SECTORS={1  2  3  4  5  6  7  8 } ] [, SMOOTHING=value ] [, /SPHERE] [, START=vector ]
Kriging Keywords:
[ METHOD='Kriging'  /KRIGING [, ANISOTROPY=vector ] [, DELTA=vector ] [, DIMENSION=vector ] [, TRIANGLES=array [, EMPTY_SECTORS=value ] [, MAX_PER_SECTOR=value ] [, MIN_POINTS=value ] [, SEARCH_ELLIPSE=vector ] ] [, FAULT_POLYGONS=vector ] [, FAULT_XY=array ] [, /GRID, XOUT=vector, YOUT=vector ] [, MISSING=value ] [, SECTORS={1  2  3  4  5  6  7  8 } ] [, /SPHERE] [, START=vector ] [, VARIOGRAM=vector ]
Linear Interpolation Keywords: [ METHOD='Linear'  /LINEAR , TRIANGLES=array [, DELTA=vector ] [, DIMENSION=vector ] [, /GRID, XOUT=vector, YOUT=vector ] [, MISSING=value ] [, START=vector ]
Minimum Curvature Keywords: [ METHOD='MinimumCurvature'  /MIN_CURVATURE [, DELTA=vector ] [, DIMENSION=vector ] [, START=vector ]
Modified Shepard’s Keywords:
[ METHOD='ModifiedShepards'  /SHEPARDS, TRIANGLES=array [, ANISOTROPY=vector ] [, DELTA=vector ] [, DIMENSION=vector ] [, EMPTY_SECTORS=value ] [, FAULT_POLYGONS=vector ] [, FAULT_XY=array ] [, /GRID, XOUT=vector, YOUT=vector ] [, MAX_PER_SECTOR=value ] [, MIN_POINTS=value ] [, MISSING=value ] [, NEIGHBORHOOD=array ] [, SEARCH_ELLIPSE=vector ] [, SECTORS={1  2  3  4  5  6  7  8 } ] [, START=vector ]
Natural Neighbor Keywords: [ METHOD='NaturalNeighbor'  /NATURAL_NEIGHBOR, TRIANGLES=array [, /DEGREES ] [, DELTA=vector ] [, DIMENSION=vector ] [, /GRID, XOUT=vector, YOUT=vector ] [, MISSING=value ] [, /SPHERE] [, START=vector ]
Nearest Neighbor Keywords: [ METHOD='NearestNeighbor'  /NEAREST_NEIGHBOR, TRIANGLES=array [, /DEGREES ] [, DELTA=vector ] [, DIMENSION=vector ] [, FAULT_POLYGONS=vector ] [, FAULT_XY=array ] [, /GRID, XOUT=vector, YOUT=vector ] [, MISSING=value ] [, /SPHERE] [, START=vector ]
Polynomial Regression Keywords:METHOD
='PolynomialRegression'  /POLYNOMIAL_REGRESSION, [, DELTA=vector ] [, DIMENSION=vector ] [, TRIANGLES=array [, EMPTY_SECTORS=value ] [, MAX_PER_SECTOR=value ] [, MIN_POINTS=value ] [, SEARCH_ELLIPSE=vector ] ] [, FAULT_POLYGONS=vector ] [, FAULT_XY=array ] [, /GRID, XOUT=vector, YOUT=vector ] [, MISSING=value ] [, POWER=value ] [, SECTORS={1  2  3  4  5  6  7  8 } ] [, START=vector ]
Quintic Keywords:METHOD
='Quintic'  /QUINTIC, TRIANGLES=array [, DELTA=vector ] [, DIMENSION=vector ] [, MISSING=value ] [, START=vector ]
Radial Basis Function Keywords:METHOD
='RadialBasisFunction'  /RADIAL_BASIS_FUNCTION, [, ANISOTROPY=vector ] [, /DEGREES ] [, DELTA=vector ] [, DIMENSION=vector ] [, TRIANGLES=array [, EMPTY_SECTORS=value ] [, MAX_PER_SECTOR=value ] [, MIN_POINTS=value ] [, SEARCH_ELLIPSE=vector ] ] [, FAULT_POLYGONS=vector ] [, FAULT_XY=array ] [, FUNCTION_TYPE={ 0  1  2  3  4 } ] [, /GRID, XOUT=vector, YOUT=vector ] [, MISSING=value ] [, SECTORS={1  2  3  4  5  6  7  8 } ] [, SMOOTHING=value ] [, /SPHERE] [, START=vector ]
Return Value
If any of the input arguments are double precision, Result is double precision; otherwise, Result is single precision. All computations are performed in double precision.
Arguments
X, Y, Z
The point locations. If only one input coordinate parameter is supplied, the points are interleaved; for the Cartesian coordinate system the points are 2byn dimensions; and 3byn for a sphere in Cartesian coordinates.
F
The function value at each location in the form of an nelement vector.
Note: GRIDDATA will use the minimum number of points specified in any of the X, Y, Z, or F array arguments as the number of input points and function values.
Lon, Lat
These arguments contain the locations (on a sphere) of the data points (similar to X, and Y) but are in degrees or radians (default) depending on the use of the keyword DEGREES.
Keywords
ANISOTROPY
This keyword is a vector describing an ellipse (see the description for the SEARCH_ELLIPSE keyword). All points on the circumference of the ellipse have an equal influence on a point at the center of the ellipse.
For example, assume that atmospheric data are being interpolated, with one dimension being altitude, and the other dimension representing distance from a point. If the vertical mixing is half that of the horizontal mixing, a point 100 units from an interpolate and at the same level has the same influence as a point 50 units above or below the interpolate at the same horizontal location. This effect requires setting the ANISOTROPY keyword to [2, 1, 0] which forms an ellipse with an Xaxis length twice as long as its Yaxis length.
DEGREES
By default, all angular inputs and keywords are assumed to be in radian units. Set the DEGREES keyword to change the angular input units to degrees (or Cartesian coordinates).
Note: If you have used GRID_INPUT to preprocess your data, you should be sure to set the DEGREES keyword.
DELTA
A twoelement array specifying the grid spacing in X and Y.
If this keyword is not specified, or if one of the elements is set equal to zero, the grid spacing is determined from the values of the DIMENSION and START keywords, according to the following rules:
 DELTA_{0} = (max(x)  START_{0})/(DIMENSION_{0}  1)
 DELTA_{1} = (max(y)  START_{1})/(DIMENSION_{1}  1)
DELTA can also be set to a scalar value to be used for the grid size in both X and Y.
This keyword is ignored if the GRID, XOUT and YOUT keywords are specified.
DIMENSION
A two element array specifying the grid dimensions in X and Y. Default value is 25 for each dimension. This keyword can also be set to a scalar value to be used for the grid spacing in both X and Y.
This keyword is ignored if the GRID, XOUT and YOUT keywords are specified.
EMPTY_SECTORS
This keyword defines the search rules for the maximum number of sectors that may be empty when interpolating at each point. If this number or more sectors contain no data points, considering the search ellipse and/or the fault polygons, the resulting interpolant is the missing data value.
Note: The TRIANGLES keyword is required when the EMPTY_SECTORS, MAX_PER_SECTOR, MIN_POINTS, or SEARCH_ELLIPSE keywords are used.
FAULT_POLYGONS
Set this keyword to an array containing one or more polygon descriptions. A polygon description is an integer or longword array of the form: [n, i_{0}, i_{1}, ..., i_{n}_{–1}], where n is the number of vertices that define the polygon, and i_{0}...i_{n}_{–1} are indices into the FAULT_XY vertices. The FAULT_POLYGON array may contain multiple polygon descriptions that have been concatenated. To have this keyword ignore an entry in the FAULT_POLYGONS array, set the vertex count, n, and all associated indices to 0. To end the drawing list, even if additional array space is available, set n to –1. If this keyword is not specified, a single connected polygon is generated from FAULT_XY.
Note: FAULT_POLYGONS are not supported with spherical gridding.
FAULT_XY
The a 2byn array specifying the coordinates of points on the fault lines/polygons.
Note: FAULT_XY is not supported with spherical gridding.
FUNCTION_TYPE
Note: This keyword is only used with the Radial Basis Function method of interpolation.
Set this keyword to one of the values shown in the following table to indicate which basis function to use. Default is 0, the Inverse Multiquadric function.
Value
Function Type Used

Equation
0
Inverse Multiquadric


1
Multilog

2
Multiquadric

3
Natural Cubic Spline


4
Thin Plate Spline


In the equations, h = the anisotropically scaled distance from the interpolant to the node, and R^{2} = the value of the SMOOTHING keyword.

GRID
The GRID keyword controls how the XOUT and YOUT vectors specify where interpolates are desired.
If GRID is set, XOUT and YOUT must also be specified. Interpolation is performed on a regular or irregular grid specified by the vectors XOUT with m elements and YOUT with n elements. The Result is an mbyn grid with point [i, j] resulting from the interpolation at (XOUT[i], YOUT[j]). When XOUT and YOUT are used, the DELTA, DIMENSION and START keywords are ignored.
INVERSE_DISTANCE
Selects the Inverse Distance method of interpolation.
KRIGING
Selects the Kriging method of interpolation. The variogram type for the Kriging method is set by default, however the VARIOGRAM keyword can be used to set variogram parameters.
LINEAR
Selects the Linear method of interpolation. The TRIANGLES keyword is required when the LINEAR keyword is used.
MAX_PER_SECTOR
This keyword defines the search rules for the maximum number of data points to include in each sector when interpolating. Search rules effectively limit the number of data points used in computing each interpolate. For example, to use the nearest n nodes to compute each interpolant, specify MAX_PER_SECTOR = n and use the TRIANGLES keyword.
Note: The TRIANGLES keyword is required when the EMPTY_SECTORS, MAX_PER_SECTOR, MIN_POINTS, or SEARCH_ELLIPSE keywords are used.
METHOD
A string containing one of the method names as shown in the following table. The default for METHOD is “InverseDistance”.
Note: The interpolation method can be chosen using the METHOD keyword set to the specific string, or by setting the corresponding method name keyword.
Note: There are no spaces between words in the method strings and the strings are case insensitive.
Method String
Meaning
"InverseDistance"

Data points closer to the grid points have more effect than those which are further away.

"Kriging"
Data points and their spatial variance are used to determine trends which are applied to the grid points.

"Linear"
Grid points are linearly interpolated from triangles formed by Delaunay triangulation.

"MinimumCurvature"

A plane of grid points is conformed to the data points while trying to minimize the amount of bending in the plane.

"ModifiedShepards"

Inverse Distance weighted with the least squares method.

"NaturalNeighbor"

Each interpolant is a linear combination of the three vertices of its enclosing Delaunay triangle and their adjacent vertices.

"NearestNeighbor"

The grid points have the same value as the nearest data point.

"PolynomialRegression"

Each interpolant is a leastsquares fit of a polynomial in X and Y of the specified power to the specified data points.

"Quintic"
Grid points are interpolated with quintic polynomials from triangles formed by Delaunay triangulation.

"RadialBasisFunction"

The effects of data points are weighted by a function of their radial distance from a grid point.

MIN_CURVATURE
Selects the Minimum Curvature method of interpolation.
Note: If the Cholesky factorization used within the Minimum Curvature method fails, then a scalar 0 will be returned instead of the twodimensional array.
Note: The minimum curvature algorithm requires a work array that is M^{2} in size, where M is the total number of input data points. On 32bit platforms, you are therefore limited to input data arrays that have less than approximately 46340 data points, with the exact number depending upon your available memory. Using an input array with too many elements will result in an error.
MIN_POINTS
If fewer than this number of data points are encountered in all sectors, the value of the resulting grid point is set to the value of the MISSING keyword.
The MIN_POINTS keyword also indicates the number of closest points used for each local fit, if SEARCH_ELLIPSE isn’t specified.
Note: The TRIANGLES keyword is required when the EMPTY_SECTORS, MAX_PER_SECTOR, MIN_POINTS, or SEARCH_ELLIPSE keywords are used.
MISSING
Set this keyword to the value that will be used for an element of the Result array if there is no calculated value for that element. The default is 0.
NATURAL_NEIGHBOR
Selects the Natural Neighbor method of interpolation.
Note: The TRIANGLES keyword is required when the NATURAL_NEIGHBOR keyword is used.
NEAREST_NEIGHBOR
Selects the Nearest Neighbor method of interpolation.
Note: The TRIANGLES keyword is required when the NEAREST_NEIGHBOR keyword is used.
NEIGHBORHOOD
Note: The NEIGHBORHOOD keyword is only used for the Modified Shepard’s method of interpolation.
A twoelement array, [Nq, Nw] defining the quadratic fit, Nq, and weighting, Nw, neighborhood sizes for the Modified Shepard’s method. The default for Nq is the smaller of 13 and the number of points minus 1, with a minimum of 5. The default for Nw is the smaller of 19 and the number of points. The Modified Shepard’s method first computes the coefficients of a quadratic fit for each input point, using its Nq closest neighbors.
When interpolating an output point, the quadratic fits from the Nw closest input points are weighted inversely by a function of distance and then combined. The size of the neighborhood used for Shepard’s method interpolation may also be specified by the search rules keywords.
POLYNOMIAL_REGRESSION
Selects the Polynomial Regression method for interpolation. The power of the polynomial regression is set to 2 by default, however the POWER keyword can be used to change the power to 1 or 3.
The function fit to each interpolant corresponding to the POWER keyword set equal to 1, 2 (the default), and 3 respectively is as follows:
By inspection, a minimum of three data points are required to fit the linear polynomial, six data points for the second polynomial equation (where POWER = 2), and ten data points for the third polynomial (POWER = 3). If not enough data points exist for a given interpolant, the missing data values are set to the value of the MISSING keyword.
POWER
The weighting power of the distance, or the maximum order in the polynomial fitting function. For polynomial regression, this value is either 1, 2 (the default), or 3.
Note: The POWER keyword is only used for the Inverse Distance and Polynomial Regression methods of interpolation.
QUINTIC
Selects the triangulation with Quintic interpolation method.
Note: The TRIANGLES keyword is required when the QUINTIC keyword is used.
RADIAL_BASIS_FUNCTION
Selects the Radial Basis Function method of interpolation.
SEARCH_ELLIPSE
This keyword defines the search rules as a scalar or vector of from 1 to 3 elements that specify an ellipse or circle in the form [R1], [R1, R2], or [R1, R2, Theta]. R1 is one radius, R2 the other radius, and Theta describes the angle between the Xaxis to the R1axis, counterclockwise, in degrees or radians as specified by the DEGREES keyword. Only data points within this ellipse, centered on the location of the interpolate, are considered. If not specified, or 0, this distance test is not applied. Search rules effectively limit the number of data points used in computing each interpolate.
For example, to only consider data points within a distance of 5 units of each interpolant, specify the keyword as SEARCH_ELLIPSE = 5.
Note: The TRIANGLES keyword is required when the EMPTY_SECTORS, MAX_PER_SECTOR, MIN_POINTS, or SEARCH_ELLIPSE keywords are used.
SECTORS
This keyword defines the search rules for the number of sectors used in applying the MAX_PER_SECTOR, EMPTY_SECTORS, and MIN_POINTS tests, an integer from 1 (the default setting) to 8.
Using the SECTORS keyword divides up the region around each output grid point into slices (like pieces of a pie or pizza). It still does the interpolation for each grid point based upon all of the input data points surrounding the desired grid point, but it now takes into account the number of empty sectors (the EMPTY_SECTORS keyword), the number of input data points within each sector (the MAX_PER_SECTOR keyword), and the total number of input data points within all sectors (the MIN_POINTS keyword). The SEARCH_ELLIPSE keyword can be used to change the shape of the region.
SHEPARDS
Selects the Modified Shepard’s method of interpolation. The parameters for the Modified Shepard’s method are set by default, however the NEIGHBORHOOD keyword can be used to modify the parameters.
Note: The TRIANGLES keyword is required when the SHEPARDS keyword is used.
SMOOTHING
A scalar value defining the smoothing radius. For the Radial Basis Function method, if SMOOTHING is not specified, the default value is equal to the average point spacing, assuming a uniform distribution. For the Inverse Distance method, the default value is 0, implying no smoothing.
Note: The SMOOTHING keyword is used only for the Inverse Distance and Radial Basis Function methods of interpolation.
SPHERE
If set, data points lie on the surface of a sphere.
When the SPHERE keyword is used with Cartesian input coordinates (x,y,z), the coordinates must lie on a unit sphere (i.e., center at 0,0,0 and radius = 1). If any points do not lie on the sphere (within some tolerance), they are forced to be on the sphere, and GRIDDATA issues a warning and continues execution.
Furthermore, if a point lies at the origin, GRIDDATA throws an error that Cartesian coordinates cannot be zero, and halts execution.
START
A scalar or a twoelement array specifying the start of the grid in X and Y. Default value is [min(x), min(y)].
This keyword is ignored if the GRID, XOUT and YOUT keywords are specified.
TRIANGLES
A 3bynt longword array describing the connectivity of the input points, as returned by TRIANGULATE, where nt is the number of triangles. If duplicate point locations are input and the TRIANGLES keyword is present, only one of the points is considered.
Note: The TRIANGLES keyword is required for the Natural Neighbor, Nearest Neighbor, Modified Shepard’s, Linear, and Quintic Interpolation methods.
Note: The TRIANGLES keyword is required when the EMPTY_SECTORS, MAX_PER_SECTOR, MIN_POINTS, or SEARCH_ELLIPSE keywords are used.
VARIOGRAM
Specifies the variogram type and parameters for the Kriging method. This parameter is a vector of one to four elements in the form of: [ Type, Range, Nugget, Scale]. The Type is encoded as:
 1  Linear,
 2  Exponential,
 3  Gaussian,
 4  Spherical.
Defaults values are: Type is Exponential, Range is 8 times the average point spacing assuming a uniform distribution, Nugget is zero, and Scale is 1.
The graph below shows the covariance equations for the four different models:
In the above equations, N is the Nugget value, S is the Scale, and R is the Range. The value d is the distance from a point in the input array to a point in the result. All four models have a covariance weighting of N + S at d=0. The Linear and Spherical models are both zero for d > R.
XOUT
If the GRID keyword is set, use XOUT to specify irregularly spaced rectangular output grids. If XOUT is specified, YOUT must also be specified. When XOUT and YOUT are used, the DELTA, DIMENSION and START keywords are ignored.
If GRID is not set (the default), the location vectors XOUT and YOUT directly contain the X and Y values of the interpolates, and must have the same number of elements. The Result has the same structure and number of elements as XOUT and YOUT, with point [i] resulting from the interpolation at (XOUT[i], YOUT[i]).
YOUT
If the GRID keyword is set, use YOUT to specify irregularly spaced rectangular output grids. If YOUT is specified, XOUT must also be specified. When XOUT and YOUT are used, the DELTA, DIMENSION and START keywords are ignored.
If GRID is not set (the default), the location vectors XOUT and YOUT directly contain the X and Y values of the interpolates, and must have the same number of elements. The Result has the same structure and number of elements as XOUT and YOUT, with point [i] resulting from the interpolation at (XOUT[i], YOUT[i]).
Examples
Examples one through four below all use the same set of variables. Execute the code below before executing the examples:
Griddata Example Variables
n = 100 seed = 121147L x = RANDOMU(seed, n)
y = RANDOMU(seed, n)
f = 3 * EXP(((9*x2)^2 + (79*y)^2)/4) + $
3 * EXP(((9*x+1)^2)/49  (10.9*y)) + $
2 * EXP(((9*x7)^2 + (69*y)^2)/4)  $
EXP((9*x4)^2  (29*y)^2)
Example 1
This example interpolates a data set measured on an irregular grid. Various types of the Inverse Distance interpolation method (the default method) are used in this example. (Note: be sure you have created the Griddata Example Variables.)
WINDOW, 0, XSIZE = 512, YSIZE = 768, TITLE = 'Inverse Distance'
!P.MULTI = [0, 1, 3, 0, 0]
grid = GRIDDATA(x, y, f)
SURFACE, grid, CHARSIZE = 3, TITLE = 'Simple Example'
grid = GRIDDATA(x, y, f, START = 0, DELTA = 0.02, DIMENSION = 51)
SURFACE, grid, CHARSIZE = 3, TITLE = 'Larger Grid'
grid = GRIDDATA(x, y, f, START = 0, DELTA = 0.02, DIMENSION = 51, $
SMOOTH = 0.05)
SURFACE, grid, CHARSIZE = 3, TITLE = 'Smoothing'
!P.MULTI = 0
Example 2
This example uses the same data as the previous one, however in this example we use the Radial Basis Function and the Modified Shepard’s interpolation methods.
WINDOW, 0, XSIZE = 512, YSIZE = 640, $
TITLE = 'Different Methods of Gridding'
!P.MULTI = [0, 1, 2, 0, 0]
grid = GRIDDATA(x, y, f, START = 0, DELTA = 0.02, DIMENSION = 51, $
/RADIAL_BASIS_FUNCTION, FUNCTION_TYPE = 1)
SURFACE, grid, CHARSIZE = 3, TITLE = 'Radial Basis Function'
TRIANGULATE, x, y, tr
grid = GRIDDATA(x, y, f, START = 0, DELTA = 0.02, DIMENSION = 51, $
TRIANGLES = tr, /SHEPARDS)
SURFACE, grid, CHARSIZE = 3, TITLE = "Modified Shepard's Method"
!P.MULTI = 0
Example 3
This example uses the same data as the previous ones, however in this example we use various types of the Polynomial Regression interpolation method.
WINDOW, 0, XSIZE = 512, YSIZE = 768, $
TITLE = 'Polynomial Regression'
!P.MULTI = [0, 1, 3, 0, 0]
TRIANGULATE, x, y, tr
grid = GRIDDATA(x, y, f, START = 0, DELTA = 0.02, DIMENSION = 51, $
TRIANGLES = tr, /POLYNOMIAL_REGRESSION)
SURFACE, grid, CHARSIZE = 3, TITLE = 'Global Degree 2 Polynomial'
grid = GRIDDATA(x, y, f, START = 0, DELTA = 0.02, DIMENSION = 51, $
TRIANGLES = tr, /POLYNOMIAL_REGRESSION, MAX_PER_SECTOR = 10)
SURFACE, grid, CHARSIZE = 3, TITLE = 'Local Polynomial, 10 Point'
grid = GRIDDATA(x, y, f, START = 0, DELTA = 0.02, DIMENSION = 51, $
TRIANGLES = tr, /POLYNOMIAL_REGRESSION, SEARCH_ELLIPSE = 0.4)
SURFACE, grid, CHARSIZE = 3, $
TITLE = 'Local Polynomial, Radius = 0.4'
!P.MULTI = 0
Example 4
This example uses the same data as the previous ones; however, in this example we show how to speed up the interpolation by limiting the interpolation to the local area around each interpolate.
Note: The inverse distance, kriging, polynomial regression, and radial basis function methods are, by default, global methods in which each input node affects each output node. With these methods, large datasets can require a prohibitively long time to compute unless the scope of the interpolation is limited to a local area around each interpolate by specifying search rules. In fact, the radial basis function requires time proportional to the cube of the number of input points.
For example, with 2,000 input points, a typical workstation required 500 seconds to interpolate a 10,000 point grid using radial basis functions. By limiting the size of the fit to the 20 closest points to each interpolate, via the MIN_POINTS keyword, the time required dropped to less than a second.
WINDOW, 0, XSIZE = 512, YSIZE = 640, $
TITLE = 'Radial Basis Function'
!P.MULTI = [0, 1, 2, 0, 0]
grid = GRIDDATA(x, y, f, START = 0, DELTA = 0.02, DIMENSION = 51, $
/RADIAL_BASIS_FUNCTION)
SURFACE, grid, CHARSIZE = 3, TITLE = 'All Points'
TRIANGULATE, x, y, tr
grid = GRIDDATA(x, y, f, START = 0, DELTA = 0.02, DIMENSION = 51, $
/RADIAL_BASIS_FUNCTION, MIN_POINTS = 15, TRIANGLES = tr)
SURFACE, grid, CHARSIZE = 3, TITLE = 'Nearest 15 Points'
!P.MULTI = 0
Example 5
This example interpolates a spherical data set measured on an irregular grid. We use the Kriging and Natural Neighbors interpolation methods in this example.
To begin, we will create a 100 scattered points on a sphere and form a function of their latitude and longitude. Then grid them to a 2 degree grid over the sphere, display a Mollweide projection map, and overlay the contours of the result on the map.
n = 100
delta = 2
dims = [360, 180]/delta
lon = RANDOMU(seed, n) * 360  180
lat = ACOS(2*RANDOMU(seed, n)  1.) * !RADEG  90
lon_grid = FINDGEN(dims[0]) * delta  180
lat_grid = FINDGEN(dims[1]) * delta  90
f = SIN(2*lon*!DTOR) + COS(lat*!DTOR)
Next, grid the data to a twodegree grid over the sphere, display a Mollweide projection map, and overlay the contours of the result on the map.
WINDOW, 0, XSIZE = 512, YSIZE = 768, TITLE = 'Spherical Gridding'
!P.MULTI = [0, 1, 3, 0, 0]
z = GRIDDATA(lon, lat, f, /KRIGING, /DEGREES, START = 0, /SPHERE, $
DELTA = delta, DIMENSION = dims)
MAP_SET, /MOLLWEIDE, /ISOTROPIC, /HORIZON, /GRID, CHARSIZE = 3, $
TITLE = 'Sphere: Kriging'
CONTOUR, z, lon_grid, lat_grid, /OVERPLOT, NLEVELS = 10, /FOLLOW
Next, we add a call to QHULL to triangulate the points on the sphere, and to then interpolate using the 10 closest points. The gridding portion of this example requires about onefourth the time as above.
QHULL, lon, lat, tr, /DELAUNAY, SPHERE = s
z = GRIDDATA(lon, lat, f, /DEGREES, START = 0, DELTA = delta, $
DIMENSION = dims, TRIANGLES = tr, MIN_POINTS = 10, /KRIGING, $
/SPHERE)
MAP_SET, /MOLLWEIDE, /ISOTROPIC, /HORIZON, /GRID, /ADVANCE, $
CHARSIZE = 3, TITLE = 'Sphere: Kriging, 10 Closest Points'
CONTOUR, z, lon_grid, lat_grid, /OVERPLOT, NLEVELS = 10, /FOLLOW
WSHOW, 0
Finally, we use the natural neighbor method, which is about four times faster than the above example but does not give as smooth a surface:
z = GRIDDATA(lon, lat, f, /DEGREES, START = 0, DELTA = delta, $
DIMENSION = dims, /SPHERE, /NATURAL_NEIGHBOR, TRIANGLES = tr)
MAP_SET, /MOLLWEIDE, /ISOTROPIC, /HORIZON, /GRID, /ADVANCE, $
CHARSIZE = 3, TITLE = 'Sphere: Natural Neighbor'
CONTOUR, z, lon_grid, lat_grid, /OVERPLOT, NLEVELS = 10, /FOLLOW
WSHOW, 0
!P.MULTI = 0
Example 6
The following example uses the data from the irreg_grid1.txt ASCII file. This file contains scattered elevation data of a model of an inlet. This scattered elevation data contains two duplicate locations.
The GRID_INPUT procedure is used to omit the duplicate locations for the GRIDDATA function. The GRIDDATA function is then used to grid the data using the Radial Basis Function method. This method is specified by setting the METHOD keyword the RadialBasisFunction string, although it could easily be done using the RADIAL_BASIS_FUNCTION keyword.
Note: Execute all of the following example sections in the order they are presented here.
First, we import the data:
file = FILEPATH('irreg_grid1.txt', $
SUBDIRECTORY = ['examples', 'data'])
dataStructure = READ_ASCII(file)
dataArray = TRANSPOSE(dataStructure.field1)
x = dataArray[*, 0]
y = dataArray[*, 1]
data = dataArray[*, 2]
Next, we display the data by scaling it to range from 1 to 253 so a color table can be applied. The values of 0, 254, and 255 are reserved as outliers. We tell IDL to use decomposed color mode (a maximum of 256 colors) and load a color table, then plot the data and show the data values in color.
scaled = BYTSCL(data, TOP = !D.TABLE_SIZE  4) + 1B
DEVICE, DECOMPOSED = 0
LOADCT, 38
WINDOW, 0
PLOT, x, y, /XSTYLE, /YSTYLE, LINESTYLE = 1, $
TITLE = 'Original Data, Scaled (1 to 253)', $
XTITLE = 'x', YTITLE = 'y'
FOR i = 0L, (N_ELEMENTS(x)  1) DO PLOTS, x[i], y[i], PSYM = 1, $
SYMSIZE = 2., COLOR = scaled[i]
Next, we grid the data using the radial basis function method:
GRID_INPUT, x, y, data, xSorted, ySorted, dataSorted
gridSize = [51, 51]
slope = (MAX(xSorted)  MIN(xSorted))/(gridSize[0]  1)
intercept = MIN(xSorted)
xGrid = (slope*FINDGEN(gridSize[0])) + intercept
slope = (MAX(ySorted)  MIN(ySorted))/(gridSize[1]  1)
intercept = MIN(ySorted)
yGrid = (slope*FINDGEN(gridSize[1])) + intercept
grid = GRIDDATA(xSorted, ySorted, dataSorted, $
DIMENSION = gridSize, METHOD = 'RadialBasisFunction')
Finally, we open a second display window and contour the Radial Basis Function results:
WINDOW, 1
scaled = BYTSCL(grid, TOP = !D.TABLE_SIZE  4) + 1B
CONTOUR, scaled, xGrid, YGrid, /XSTYLE, /YSTYLE, /FILL, $
LEVELS = BYTSCL(INDGEN(18), TOP = !D.TABLE_SIZE  4) + 1B, $
C_COLORS = BYTSCL(INDGEN(18), TOP = !D.TABLE_SIZE  4) + 1B, $
TITLE = 'The Resulting Grid with Radial Basis Function', $
XTITLE = 'x', YTITLE = 'y'
Example 7
The following example uses the data from the irreg_grid1.txt ASCII file. This file contains scattered elevation data of a model of an inlet. This scattered elevation data contains two duplicate locations. The same data is used in the previous example.
The GRID_INPUT procedure is used to omit the duplicate locations for the GRIDDATA function. The GRIDDATA function is then used to grid the data using the Radial Basis Function method. This method is specified by setting the METHOD keyword the RadialBasisFunction string, although it could easily be done using the RADIAL_BASIS_FUNCTION keyword.
Faulting is also applied in this example. First, a fault area is placed around the right side of the dataset. This fault area contains data points. The data points within this area are gridded separately from the points outside of the fault area.
Then, a fault area is defined within an region that does not contain any data points. Since this fault area does not contain any points, the grid within this region results to the value defined by the MISSING keyword. The points outside of the fault area are gridded independent of the fault region.
Note: Execute all of the following example sections in the order they are presented here.
First, we import the data:
file = FILEPATH('irreg_grid1.txt', $
SUBDIRECTORY = ['examples', 'data'])
dataStructure = READ_ASCII(file)
dataArray = TRANSPOSE(dataStructure.field1)
x = dataArray[*, 0]
y = dataArray[*, 1]
data = dataArray[*, 2]
Do some preprocessing before gridding the data. GRID_INPUT will remove any duplicate locations.
GRID_INPUT, x, y, data, xSorted, ySorted, dataSorted
gridSize = [51, 51]
slope = (MAX(xSorted)  MIN(xSorted))/(gridSize[0]  1)
intercept = MIN(xSorted)
xGrid = (slope*FINDGEN(gridSize[0])) + intercept
slope = (MAX(ySorted)  MIN(ySorted))/(gridSize[1]  1)
intercept = MIN(ySorted)
yGrid = (slope*FINDGEN(gridSize[1])) + intercept
Grid the data with a fault area containing data points:
faultVertices0 = [[2200, 4000], [2200, 3000], [2600, 2700], $
[2600, 50], [5050, 50], [5050, 4000], [2200, 4000]]
faultConnectivity0 = [7, 0, 1, 2, 3, 4, 5, 6, 1]
grid0 = GRIDDATA(xSorted, ySorted, dataSorted, $
DIMENSION = gridSize, METHOD = 'RadialBasisFunction', $
FAULT_XY = faultVertices0, $
FAULT_POLYGONS = faultConnectivity0, $
MISSING = MIN(dataSorted))
Grid the data again with a fault area that does not contain data points:
faultVertices1 = [[2600, 50], [2800, 50], [2800, 2700], $
[2400, 3000], [2400, 4000], [2200, 4000], [2200, 3000], $
[2600, 2700], [2600, 50]]
faultConnectivity1 = [9, 0, 1, 2, 3, 4, 5, 6, 7, 8, 1]
grid1 = GRIDDATA(xSorted, ySorted, dataSorted, $
DIMENSION = gridSize, METHOD = 'RadialBasisFunction', $
FAULT_XY = faultVertices1, $
FAULT_POLYGONS = faultConnectivity1, $
MISSING = MIN(dataSorted))
Finally, we tell IDL to use decomposed color mode (a maximum of 256 colors) and load a color table, then display our gridded results:
DEVICE, DECOMPOSED = 0
LOADCT, 38
WINDOW, 0, XSIZE = 600, YSIZE = 600, $
TITLE = 'The Resulting Grid from the Radial Basis Function '+ $
'Method with Faulting'
!P.MULTI = [0, 1, 2, 0, 0]
CONTOUR, BYTSCL(grid0), xGrid, YGrid, /XSTYLE, /YSTYLE, /FILL, $
LEVELS = BYTSCL(INDGEN(18)), C_COLORS = BYTSCL(INDGEN(18)), $
TITLE = 'Fault Area Contains Data ' + $
'(Fault Area in Dashed Lines)', XTITLE = 'x', YTITLE = 'y'
PLOTS, faultVertices0, /DATA, LINESTYLE = 2, THICK = 2
CONTOUR, BYTSCL(grid1), xGrid, YGrid, /XSTYLE, /YSTYLE, /FILL, $
LEVELS = BYTSCL(INDGEN(18)), C_COLORS = BYTSCL(INDGEN(18)), $
TITLE = 'Fault Area Does Not Contain Data '+ $
'(Fault Area in Dashed Lines)', XTITLE = 'x', YTITLE = 'y'
PLOTS, faultVertices1, /DATA, LINESTYLE = 2, THICK = 2
!P.MULTI = 0
References
Kriging
Isaaks, E. H., and Srivastava, R. M., An Introduction to Applied Geostatistics, Oxford University Press, New York, 1989.
Minimum Curvature
Barrodale, I., et al, "Warping Digital Images Using Thin Plate Splines", Pattern Recognition, Vol 26, No 2, pp. 375376., 1993.
Powell, M.J.D., “Tabulation of thin plate splines on a very fine twodimensional grid”, Report No. DAMTP 1992/NA2, University of Cambridge, Cambridge, U.K. 1992.
Modified Shepard’s
Franke, R., and Nielson, G. , "Smooth Interpolation of Large Sets of Scattered Data", International Journal for Numerical Methods in Engineering, v. 15, 1980, pp. 16911704.
Renka, R. J., Algorithm 790  CSHEP2D: Cubic Shepard Method for Bivariate Interpolation of Scattered Data, Robert J. Renka, ACM Trans. Math Softw. 25, 1 (March 1999), pp. 7073.
Shepard, D., "A Two Dimensional Interpolation Function for Irregularly Spaced Data", Proc. 23rd Nat. Conf. ACM, 1968, pp. 517523.
Natural Neighbor
Watson, D. F., Contouring: A Guide to the Analysis and Display of Spatial Data, Pergamon Press, ISBN 0 08 040286 0, 1992.
Watson, D. F., Nngridr  An Implementation of Natural Neighbor Interpolation, David Watson, P.O. Box 734, Clarement, WA 6010, Australia, 1994.
Quintic
Akima, H., Algorithm 761  Scattereddata Surface Fitting that has the Accuracy of a Cubic Polynomial, Hiroshi Akima, ACM Trans. Math. Softw. 22, 3 (Sep. 1996), pp. 362  371.
Renka, R.J., "A Trianglebased C1 Interpolation Method", Rocky Mountain Journal of Mathematics, Vol 14, No. 1, 1984.
Radial Basis Function
Franke, R., A Critical Comparison of Some Methods for Interpolation of Scattered Data, Naval Postgraduate School, Technical Report, NPS 5379003, 1979.
Hardy, R.L., "Theory and Applications of the Multiquadricbiharmonic Method", Computers Math. With Applic, v 19, no. 8/9, 1990, pp.163208.
Version History
5.5
Introduced
8.3
For KRIGING, fix the Linear covariance function
See Also
GRID_INPUT, KRIG2D
